Product Description
Axial 1/8 AXP8 Gilamon 2.2 4X4 RTR Brushed Trail Buggy, Green
The wait is over. With the AXP8 Gilamon 2.2 RTR, Axial introduces the next level in RC rock crawling performance. It’s the most innovative and maneuverable rig you’ve ever seen.
A true rock crawler, the Gilamon isn’t made for overlanding or easy “Sunday” drives. With its 2.2-inch wheel setup and new AXP8 platform, this RC crawler has no match on the most challenging trails and obstacles. Because it’s ready-to-run, you don’t need experience to succeed. But if you have spent a lot of time on the trails, you’ll be blown away by what you can do now that was impossible before.
What’s so revolutionary about the AXP8? Let’s start with its heavy-duty, high-clearance, front and rear AF16P portal axles - and especially the rear-axle ASD (Axial Selectable Drive), a more advanced and highly capable drivetrain version of cutting brakes. While cutting brakes are only as strong as the brakes themselves, ASD physically and completely locks a wheel. It’s better than cutting brakes. And unlike front dig, which locks the entire axle, ASD can lock either of the rear wheels individually. That gives you an even tighter turning radius and greatly improved maneuvering capabilities.
The AF16P front axle and advanced new AT6 transmission are also designed to accept optional ASD setups, giving you an unprecedented amount of vehicle control. With ASD assigned to a 3-position switch on your transmitter, you can activate locking or constant 4WD functions. Using a 5-position switch, you’ll be able to configure the ASD system to drive, to free wheel, or to lock.
No RC crawler has offered this level of sophistication before. Nothing can stand in your way. The AT6 transmission is also equipped with a 30% underdrive to the rear axle that dramatically improves climbing and increases maneuverability.
Further improving the rig’s trail performance are the extreme articulation of its 4-link suspension and the additional clearance of its realistic, new IS10 internal spring shocks. An oversized, high torque Axial Boulder 550 21-turn brushed motor sends power through durable, heavy-duty WB12 driveshafts to officially licensed Raceline Avenger wheels and 5.5-inch tall Mickey Thompson Baja Boss M/T tires. Surrounding it all is a durable composite cage that offers protection and challenge-ready trail buggy looks.
The included Spektrum DX3 radio and Firma 70A ESC give you the telemetry benefits of exclusive Smart technology. Other high-quality, factory-installed Spektrum on-board electronics include a SR515 5-channel DSMR receiver, S682 metal gear steering servo, and SX117AX metal gear micro servo for the ASD function. Just add your choice of recommended battery and charger - then you’re ready to take on any obstacle that lies ahead.
Get ready to go where no crawler has gone before with the Axial AXP8 Gilamon 2.2 RTR. It’s the king of the hill, the trail, the canyon, the ledge, and everything else off-road!
Features
- Realistic scale trail buggy design
- Durable and detailed composite cage
- Innovative Axial Selectable Drive (ASD) cutting brakes
- Smooth, high-flex 4-link suspension
- Scale IS10 internal spring high-clearance shocks
- ASD-equipped AF16P high-clearance rear portal axle
- ASD-compatible AF16P heavy-duty front portal axle
- Durable new ASD-compatible AT6 transmission
- 30% Underdrive to the rear axle
- Oversized Axial Boulder 550 21-turn brushed motor
- Heavy-duty WB12 front and rear driveshafts
- Officially licensed Mickey Thompson Baja Boss M/T 2.2 tires
- Officially licensed Raceline Avenger 2.2 wheels
- Spektrum DX3 Smart 3-channel 2.4GHz transmitter
- Spektrum SR515 DSMR 5-channel receiver
- Spektrum Firma 70A brushed Smart ESC
- Spektrum S682 25T metal gear steering servo
- Spektrum SX117AX metal gear micro servo (for ASD function)
ASD (AXIAL SELECTABLE DRIVE)
Expand your strategies for overcoming obstacles with the Gilamon trail buggy’s ASD (Axial Selectable Drive), a more advanced and highly capable drivetrain version of cutting brakes. While cutting brakes are only as strong as the brakes themselves, ASD physically and completely locks a wheel. As it’s set up out of the box, you can lock either of the rear wheels for a tighter turning radius. The front axle and transmission also accept optional ASD setups.
TRAIL BUGGY DESIGN
The Gilamon has a durable, realistically detailed composite cage with Lexan body panels for protection and challenge-ready trail buggy looks. The rig comes factory-finished and is available in your choice of two color options.
AT6 TRANSMISSION
Axial puts the emphasis on durability and versatility with its all-new AT6 transmission. The transmission includes a 30% underdrive to the rear axle that dramatically improves climbing and increases maneuverability. It’s also designed to accept optional ASD (Axial Selectable Drive) setups for an unprecedented level of vehicle control.
AF16P PORTAL AXLES
Heavy-duty, high clearance AF16P portal axles are among the design innovations that increase maneuverability for success on challenging trails. The rear axle comes with ASD (Axial Selectable Drive) function installed, and the front axle is ASD compatible.
WATERPROOF SPEKTRUM ELECTRONICS
The high-quality, waterproof Spektrum on-board electronics are ideal for crawling in any conditions. The Spektrum S682 metal gear steering servo has the industry standard 25-tooth spline count and an aluminum servo horn for strength. A Spektrum SX108 metal gear micro servo is included for the ASD (Axial Selectable Drive) system.
AXIAL BOULDER 550 BRUSHED MOTOR
A big rig like the Gilamon needs a big motor. The oversized, factory-installed Axial Boulder 550 is longer than a typical 540 motor, providing more torque and greater durability. The 21-turn design offers the perfect blend of power and wheel speed.
SPEKTRUM SMART TECHNOLOGY
The included Spektrum DX3 Smart transmitter, SR515 5 channel receiver, and Firma 70A Smart ESC are ready to deliver the telemetry advantages of Smart technology. Install a Spektrum Smart LiPo battery and you’ll be able to follow vehicle battery capacity on the transmitter's voltage level indicator.
IS10 INTERNAL SPRING SHOCKS
The Gilamon features all-new, aluminum body, internal spring IS10 shocks that increase ground clearance and scale realism. Its smooth, high-flex 4-link suspension geometry reduces the effects of torque twist and provides consistent articulation without the bump steer found in 3-link designs.
LED ROCK LIGHTS
For nighttime crawling, preinstalled LED rock lights illuminate each wheel. Housed in rugged cases, the bright LEDs are clamped to the cage, which allows the lights to be moved. Multiple colors add clarity for crawling and style.
WB12 DRIVESHAFTS
Heavy-duty WB12 front and rear driveshafts offer the durability needed to withstand the abuse of crawling over rocks and rugged trails.
OFFICIALLY LICENSED MICKEY THOMPSON TIRES
The Gilamon rides on 5.5 inch tall, officially licensed Mickey Thompson Baja Boss M/T 2.2 tires. They look authentic and supply the aggressive traction needed to climb over and conquer any obstacle.
OFFICIALLY LICENSED RACELINE AVENGER 2.2 WHEELS
The classic 8-spoke design of these officially licensed Raceline Avenger 2.2 wheels adds to the Gilamon rig’s authentic scale trail buggy looks.
Specs
Approximate Assembly Time No assembly required
Ball Bearings Full set
Body Lexan Panel
Brakes Integral with ESC
Chassis Composite tube frame
Completion Level Ready-To-Run
Differential Locked
Drive Type Forward/Reverse
Drivetrain 4WD
Gear Pitch 32P
Lighting LED
LiPo Compatibility 3S
Motor Type Brushed
Pinion 14T
Power Type Electric
Product Height 9" (229 mm)
Product Length 20" (508 mm)
Product Weight 7 lb (3.2kg)
Product Width 12.6" (320 mm)
Scale 1/8
Shock Type Aluminum oil-filled internal spring
Spur Gear 34T
Suspension 4-link solid axle
Tire Type Mickey Thompson Baja Boss M/T 2.2
Vehicle Type Trail Buggy, Rock Crawler
Wheelbase 14.5" (368 mm)
Includes
(1) Axial AXP8 Gilamon 2.2 4X4 RTR
(1) Axial Boulder 550 21T Brushed Motor (installed)
(1) Spektrum S682 20kg Metal Gear Steering Servo
(1) Spektrum SX117AX Metal Gear Micro Servo, for ASD function (installed)
(1) Spektrum Firma 70A 1070 Brushed Smart ESC (installed)
(1) Spektrum SR515 Receiver (installed)
(1) Spektrum DX3 2.4GHz Transmitter
(4) AA Alkaline Transmitter Batteries
(1) Product Manual
Needed to Complete
(1) 2-3S LiPo Battery with IC3 or EC3 connector
(1) Compatible Battery Charger
